Supports 1.5V and 3V power supply (1.5V@1.15-1.65V, 3V@2.1-5V)

4-electrode optimized glucose detection anti-interference capability

µV-level noise operational amplifier combined with 16-bit high-precision Sigma Delta for pA current detection accuracy

Shelf mode power consumption less than 15nA

Bias voltage hold state， current less than 4.6µA@3V and 5.2µA@1.5V

Built-in feedback resistor, reducing PCB area, requires only 5 capacitors for 1.5V and 4 capacitors for 3V

Supports "bias voltage" and "current acquisition" power-on self-calibration

Temperature sensor accuracy parameters: ±0.5 ℃

2.4mm×2.48mm WLCSP-25
