Supply Voltage: Supports 3 V operation

Shutdown Leakage Current: <15 nA

Sensor Acquisition Circuit Noise: <6 μV

ADC Effective Resolution: 16 bits (ENOB)

ADC System Clock: Up to 64 kHz

Oversampling Ratio (OSR): 32–2,048

Integrated FIFO: 256 × 18-bit data buffer

Transimpedance Amplifier (TIA) Bias Voltage Range: 0.3–2 V, with 10-bit resolution

Programmable Feedback Resistor: Integrated on-chip to reduce PCB footprint

Bioimpedance Measurement: Integrated impedance measurement module for measuring complex human body impedance

Temperature Sensor Accuracy: ±0.5°C

Sleep Mode Current Consumption: <100 nA

Continuous Sampling Current Consumption: <35 μA
